This product adopts the latest high-end intelligent microprocessor control technology, composed of high-end vital parts such as microprocessor chips, relays, and wireless receiving modules. It is used for electric doors, windows, garage door control, light control, remote control curtains, lifting equipment, gates Roads, elevators, industrial control and security industries, etc. It has the characteristics of easy installation, safe and reliable use.

Pair remote control method

First, complete the code clearing. Press the learning button and the buzzer will beep three times and then beep a long time. Press one of the keys on the remote control. The buzzer will beep twice and then stop beeping, indicating that the code is successfully configured.

There are three working mode: Momentary/Toggle/Latching.

Press different remote button to match with receiver, working mode is different.

Momentary:

Press the Transmitter button 1 to match with receiver, the receiver relay 1th is ON, release button 1; the receiver relay 1th is OFF, the same as 2/3/4/5/6/7/8/9/10/11/12. 12CH are independent.

Toggle:

Press transmitter button 3 to match with receiver , the receiver relay 1th is ON, press button 1 again, the receiver relay 1th is OFF,the same 2/3/4/5/6/7/8/9/10/11/12. 12CH are independent.

Latching:

Press transmitter button 2 to match with receiver

note:
Press remote control key 4 to learn ——1-6 channel Momentary 7-12 Toggle

Press remote control key 5 to learn ——1-6 channel Momentary 7-12 Latching

Press remote control key 6 to learn ——1-6 channel Latching 7-12 Toggle

Press remote control key 7 to learn ——1-4 channel Momentary, 5-8 Latching, 9-12 Toggle,

Press remote control key 8 to learn ——1-6 channel Toggle, 7-12 Momentary

Clear code method:

Power on, then clear the code. Press and hold the learning button on the control panel for 8 seconds until the buzzer stops, that is, all the remote controllers that learn the code matching will be automatically cleared. After clearing, the remote control that has previously learned to code will no longer be controlled.

1).Accept OEM & ODM
2).Sample for testing could be arranged
3).Print logo on the case and pakage
4).Deliver by air mail or ship for your order
5).Your inquiry related to our products or prices will be replied in 12 hours

Standard packing :each one in a plastic bag or white box;

500 pieces in a carton, one carton weight is 12KG, carton size is 40*29*24CM . Packing can be customized.

We have strong cooperation with DHL,TNT,UPS,FEDEX,EMS,China Air Post.
You also can choose your own shipping forwarder.

Shenzhen champions Technology Co., Ltd. it is a new high-tech electronics companies, the company is committed to electronic product development, production and sales service, to create a series of wireless remote control, wireless receiver module , wireless controller , smoke detector , gas detection , wireless infrared and radio detection , door , home burglar alarm, vehicle control and alarm and so on .
Companies adhere to the customer focus, quality first, reputation first approach, in strict accordance with the requirements of production and management of ISO9001 international quality management system, providing customers with a full range of "zero defect" products and quality service.

1 .What are the advantages of your company?
A .We have our own factory and we are tarding many years;
B. Meet the requirements of the quantity OEM & ODM order available;
C.CE& ROHS certification;
D.Offer samples to test.
2. How can i know this model work for me ?
If you have a model in hand, please take a clear picture of the PCB board send to us then we will help you .
3. How long can the remote control use ?
ln generally the remote control can be used for many years Only need to replace the battery .
4. Do your products carry warranty?
Yes, 12 month warranty.
