10A 220 volts remote control on off light switch with remote AG-C114
    Publish time 2021-11-04 09:43
10A 220 volts remote control on off light switch with remote AG-C114
Product Description

10A 220 volts remote control on off light switch with remote AG-C114

My company designs multifunction one channel wireless controller is one relay output switch signal. Can make the equipment, motor reach on and off or pass conversion etc. All kinds of special control program require. Mainly used in electric doors, windows, lifting equipment, gateways, elevator, industrial control and security industry and other area.

The wireless controller with high-security, stable performance,low power consumption and easy to use, without the traditional jumper or DIP switch coding, just receive the wireless remote control signal and storage, can be achieved supporting the use of. The controller can learn the remote control of a plurality of different encoding (such as 2262,1527 etc.) with working lights, and receiver is in the on-state indicator lights, it can clearly show the working status of the receiver

Product name
Remote Control Switch
1 Channels
Working voltage
AC 220V
Learning remote way
learning mode
Receiving sensitivity
-95 dBm
Maximum load
Board size
62*35*22 mm


1. Working voltage: AC 220V

2. Working frequency: 315mhz/433mhz other frequency can be customized

3. Receiving sensitivity: -95DB

4. Coding method: learning way

5. Working way: Momentary/interlock/self-lock three modes can be changed each other

6. Output way: with voltage

7. Maximum load: 10A

8. Dimension size: 62*35*22 mm

Product Features

1. It adopts micro intelligent single-chip microcomputer to decode and the remote control can be paired with it by learning the code.

2. Single way passive output

3. Adopt wireless coding technology, non-directional, strong anti-interference ability

4. It mainly used in electric door, window, switches, auto parts, security alarm etc area.

Output Way
1). Output mode selection and learning method: Press any button of the remote control, the learning indicator should flash continuously, Otherwise this module cannot learn this remote control.(Momentary and self-lock mode require the remote control have single button that's OK, and interlock mode requires the remote control at least have two buttons)
2). Output mode selection: Press and hold the learning button on this controller panel, after about 2 seconds the leaning indicator light up, don't let go of the learning button after about 4 seconds the learning indicator light will turn off. Do not let go of the learning button, after about two seconds the learning indicator will flash once. After about two seconds the learning indicator will flash twice. After about two seconds, the learning indicator will flash three times. After the learning indicator flashes once, before the learning indicator flashes twice, release the learning button the output mode is momentary mode. After the learning indicator flashes twice, before the learning indicator flashes three times, release the learning button the output mode is self-lock. After the indicator light flashes three times, release the learning button the output mode is interlock.

Learning method

Press and hold the learning button on this controller panel, after about 2 seconds the learning indicator light up, release the leaning button and press any button of what remote you want to learn, the learning indicator light will flash three times then light that means learning success. This controller panel can memorize up to sixteen remote controls, and will cover the first memory remote control for seventeen times (currently only the button corresponding to the 13th data bit of the remote control can be controlled.); When learning the second remote control, simply light the indicator light on the controller panel, then press the remote control button that's OK)

Clear the the remote control code

Press and hold this controller panel learning button, after about the 2 seconds the learning indicator light up, don't let go of the learning button, after about 4 seconds the learning indicator light will off. That indicates all the memory codes have been cleared, if you do not want to change the control output mode, release the learning button. Then the output mode remains unchanged before the output mode is cleared.Otherwise repeat the action of 2.

Application Scope

Widely used for controlling electric doors/gates and windows ,garages door and all kinds of openers, gate barrier ,access control system, industrial control, car remote control, car alarm system, remote control switches , intelligent control, communication and security fields etc.

Packing & Delivery


Standard packing :each one in a plastic bag or white box;

500 pieces in a carton, one carton weight is 12KG, carton size is 40*29*24CM . Packing can be customized.


We have strong cooperation with DHL,TNT,UPS,FEDEX,EMS,China Air Post.
You also can choose your own shipping forwarder.

Our Service

1).Accept OEM & ODM
2).Sample for testing could be arranged
3).Print logo on the case and pakage
4).Deliver by air mail or ship for your order
5).Your inquiry related to our products or prices will be replied in 12 hours

Trade terms

1).Payment:T/T, Paypal and western union, other payment terms can negotiable
2).Bulk order 30% deposits before production,70% balance to be paid before delivery
3) .Samples can be delivered in 3-5 work days
4) .Shipping freight are quoted under your requests
5) .Discounts are offered based on order quantities
6). FOB price are quoted under inquiry
